Description
1.Versatile
Only one machine can produce different sizes and shapes air pillow ,Air Bubble ,Four Tube.
2.Easy
Easy to operate and requires minimal operator training
LCD Screen display control
Adjustable parameters in machine operation.
3.Stable
Industrial grade ,quality parts ,48 hour’s continuous operation testing.
4.Emergency
Emergency brake switch , prevent emergency protect the machine.
Specification
Applicable to big Warehouse
Model No: PAK1000D
Max Work Speed: 20M/Min
AC Input: 100-240V 50-60Hz
Total Power: 300W
Machine Weight: 17KG
Suitable Roll Film: LDPE/HDPE 200mm 400mm 600mm Width Roll
| Roll film type | Temp | speed | Air blow |
| 101（20*20cm) | 12-14 | 06 | 5-6 |
| 102（10*20cm) | 12-14 | 06 | 6-7 |
| 103 (13*20cm) | 12-14 | 06 | 5-6 |
| 401（Super Tube） | 12-14 | 06 | 15-18 |
| 501（Four Tube） | 12-14 | 06 | 10-15 |
| 601（Quilt-Air Small） | 12-14 | 06 | 17-20 |
| 701Quilt-Air Bubble） | 12-14 | 06 | 17-20 |
Air pillow bags: 80*200; 100*200; 130*200; 150*200; 200*200
Air cushion films: double cushion pillow 200*400
Super tube 150*400
Four tube 320*400
Air bubble 320*400
Mini air bubble 270*400
