Description
1.Versatile
Only one machine can produce different sizes and shapes air pillow ,Air Bubble ,Four Tube.
2.Easy
Easy to operate and requires minimal operator training
LCD Screen display control
Adjustable parameters in machine operation.
3.Stable
Industrial grade ,quality parts ,48 hour’s continuous operation testing.
4.Fast and efficient,speed up to 20m/min.
Specification
Applicable to big Warehouse
Model No: PAK1000E
Max Work Speed: 20M/Min
AC Input: 100-240V 50-60Hz
Total Power: 500W
Machine Weight: 22KG
Suitable Roll Film: LDPE/HDPE 200mm 400mm Width Roll Film Production Characteristics
| Roll Film Type | Temp | Speed | Air Blow |
| 101（20*20cm) | 08-11 | 05-06 | 01-03 |
| 102（10*20cm) | 08-11 | 05-06 | 02-03 |
| 103（13*20cm) | 08-11 | 05-06 | 01-03 |
| 401（Super Tube） | 09-12 | 03-05 | 07-15 |
| 501（Four Tube） | 09-12 | 05-06 | 07-09 |
| 601（Quilt-Air Small） | 09-12 | 05-06 | 12-15 |
| 701（ Quilt-Air Bubble） | 09-12 | 04-06 | 15 |
| 801（Quilt-Air Large） | 09-12 | 05-06 | 12-15 |
| 201（Double Cushion） | 09-12 | 05-06 | 12-15 |
Air pillow bags: 80*200; 100*200; 130*200; 150*200; 200*200
Air cushion films: double cushion pillow 200*400
Super tube 150*400
Four tube 320*400
Air bubble 320*400
Mini air bubble 270*400
